הסתעפות 90° ארוך 75 × 75 × 75

הסתעפות 90° ארוך 75 × 75 × 75

870406075

75 mm

1947 g

ISO 14236, AS/NZS 4129, ISO 7/1, BS 21, DIN 2999, UNI 9561, NEN 3258, AS 1722, DIN 8076

Maximum temperature of use for fittings and valves is the same as that for polyethylene pipe and they are not intended for use in hot water applications. They will withstand sub-zero temperatures.

NBR

Polypropylene, high-grade copolymer.

PTFE tape is strongly recoמ

Excessive torque during tightening can cause nut deformation and result in joint failure; therefore use a Plasson wrench or other spanner with handle length not greater than 46 cm. If fittings are reused, avoid pull outs by ensuring the split ring is sharp and bites into the pipe. Alternatively replace split ring.
